Máquina de inyección de cera sin cilindro de 16 toneladas para fundición a la cera perdida

Explain

Unit

YN-SMZ-16LB-YDD

Clamping force (max)

T

16

Mold use space(L×W×H)

mm

460×430×500

Up and down the mold trip

mm

400

Minimum height of the mold

mm

100

hydraulic oil tank

L

150

PLC+Touch screen

YES/NO

YES

The nozzle is electrically powered up and down

YES/NO

YES

Mold use form

Can be up and down fixed automatic mode, hand push single mode or double mode

Paraffin pressure form

Single and multiple segments can be selected

Maximum wax injection (wax cylinder)

L

3.3

Maximum injection pressure

MPa

0~10 (Hydraulic variable pressure control )
